เครื่องโทรศัพท์ PANASONIC รุ่น KX-HDV100 IP Phone (SIP) SIP Phone 1 LAN ports Panasonic (ไม่รวม Adaptor)
หมวดหมู่สินค้า: โทรศํพท์ IP
รหัส : 003256
ราคา 1,390.00 บาท

28 ตุลาคม 2563

ผู้ชม 63 ผู้ชม

เครื่องโทรศัพท์ PANASONIC รุ่น KX-HDV100

IP Phone (SIP) SIP Phone 1 LAN ports Panasonic (ไม่รวม Adaptor)

Features

  • - 1 SIP accounts
  • - 132 x 64 pixel 2.3 inch graphical LCD
  • - HD Voice (G.722)
  • - Up to 500 phonebook
  • - 3-way conference call support
  • - Compatible with Broadsoft UC one
  • - 1 x 10/100M ports
  • - Low standby power consumption
  • - XML Application Interface
  • - 2 Programmable keys
  • - Plug and Play configuration
  • - Changeable angle stand
  • - Wall mounting (Optional)

Specificaiton

Display
LCD Display Monochrome Graphical
LCD Size 132 × 64 pixel 2.3 inch Graphical LCD
LCD Contrast -
LCD Backlight -
Install Options
Desk Mount Tilt Yes - 2 positions
Wall Mount KX-A440 (optional)
Power Adaptor - (Included)
Audio Features
Handset, Speaker, Volume 8 levels (includes echo cancellation and distortion prevention)
Ringtones 27
Ringer Volume 8 levels + Off
Headset Port -
Electronic Hook Switch Control Port -
Audio Codec G.711a-law / G.711µ-law / G.722 (wideband) / G.729a
HD Voice Yes
Speaker Phone -
Keys
Programmable Keys 2
Software Features
Phonebook (Local) Up to 500
LDAP Remote Phonebook Yes
XML Remote Phonebook Yes
Call Log Entries 30 incoming calls + 30 outgoing calls
Conferencing 3 parties (within terminal – multi-party dependent on server)
XML Application -
Music on Hold Supplied by Host Service (PBX / SIP Server)
IP Features
SIP Accounts 1
SIP Compatibility RFC 3261 Standard SIP Server, Asterisk, Broadsoft, Panasonic IP PBX
IP Version IPv6 / IPv4
DHCP Client Yes
DNS Yes
HTTP Yes
HTTPS Yes
SNTP Client Yes
VLAN (802.1q) Yes
QoS (DiffServ) Yes
Configuration
Plug & Play Configuration Server based configuration, TR-069
Manual Configuration Internal web Configurator, Local (LCD based) network configuration
Interface
Ethernet Ports 1
Ethernet Interface 10/100 Mbps
PoE (Power over Ethernet) -
Others
Power Consumption

AC Adaptor
Standby: 0.9 W
Talking: 1.0 W
Max: 1.8 W

Operating Environment 0 °C - 40 °C (32 °F - 104 °F)
Dimensions
(Width x Depth x Height; excluding the handset, stand attached)
High position: 167 mm x 165 mm x 148 mm
Low position: 167 mm x 173 mm x 115 mm
Weight
(with handset, handset cord and stand)
672 g
