หมวดหมู่สินค้า: TOA
รหัส : 003707
สินค้ารับประกัน 1 ปี ราคายังไม่รวมภาษีมูลค่าเพิ่ม ค่าแรงติดตั้ง และค่าจัดส่ง
ราคา 51,740.00 บาท
03 พฤศจิกายน 2563
ผู้ชม 263 ผู้ชม
The RM-200SF is a Fireman's Microphone of the matrix system. It is equipped with an Emergency key, permitting it to be used as a remote microphone for emergency broadcast. Zone selection and microphone announcement can be made at the time of emergency broadcast. It offers a surveillance function to detect failures including microphone element failure. The RM-200SF has three function keys that can be set as individual or group selection keys, and each key is linked with the corresponding two indicators. Connecting the optional RM-210 Extension units to the RM-200SF expands the number of function keys and indicators in blocks of ten.
- * 0 dB = 1 V
| Power Source | 24 V DC (operating range: 15 - 40 V DC, supplied from the audio input unit) |
|---|---|
| Current Consumption | 240 mA or less |
| Audio Output | 0 dB*, transformer-balanced |
| Distortion | 1 % or less |
| Frequency Response | 200 Hz - 15 kHz |
| S/N Ratio | 55 dB or more |
| Microphone | Unidirectional dynamic microphone with talk key, AGC (ON/OFF switchable), microphone element failure detectable by using a built-in small oscillator |
| Volume Control | Microphone volume control, Monitor speaker volume control |
| Connection Cable | Shielded CPEV cable (each one pair of audio wire, data wire, monitor/control wire, and power supply wire) or Shielded Category 5 twisted pair cable (CAT5-STP), M3 screw terminal |
| Maximum Cable Distance | 800 m (874.89 yd) |
| No. of Connectable Expansion | Max. 5 units |
| Monitor Speaker | Built inside |
| Operation | Emergency key, Function keys, CPU switch, Reset switch |
| Indication | Status indicators, Power indicator, Failure indicator, CPU indicator, Selection indicators, Microphone indicator, Broadcast status indicator |
| Operating Temperature | 0 |
