TOA TS-920RC Center unit with Recording function
The TS-920RC is a Central Unit of the Infrared Conference System that allows easy installation and flexible layout. By connecting TS-905/907 IR Transmitter/Receiver, TS-920RC can control the Chairman and Delegate Units via wireless infrared signal. It features the installation confirmation function that allows the connection status of IR Transmitter/Receiver and Chairman/Delegate Units to be verified, and the voting function. The TS-920RC is also equipped with FBS (Feedback Suppression), enabling effective control of acoustic feedback. In addition the unit employs an MP3 recorder that makes it possible to record all conference contents to either a connected USB memory drive or internal memory. The system can be controlled by PC (*1). With the use of an optional rack mounting bracket, it can be mounted in an EIA Standard equipment rack (4 unit size).(*1) Relevant control software is supplied on a custom-made basis.
Specification
| POWER SOURCE |
100 – 240 V AC |
| POWER CONSUMPTION |
72 W |
| CURRENT CONSUMPTION |
Max. 3 A DC (when 24 V DC is supplied from the accessory AC adapter) |
| CARRIER FREQUENCY |
Reception: Audio channel 1: 7.35 MHz
Audio channel 2: 8.10 MHz
Audio channel 3: 8.55 MHz
Audio channel 4: 9.15 MHz
Control channel: 6.45 MHz
Transmission: Base language channel: 1.95 MHz
Translation language channel: 2.25 MHz |
| INPUT |
MIC 1 (Base Language): -60 dB (*2)
MIC 2 (Translation Language): -60 dB (*2)
AUX 1 (Base Language): -20 dB (*2)
AUX 2 (Translation Language): -20 dB (*2)
AUX 3 (Base and Translation Language): -20 dB (*2) |
| OUTPUT |
LINE: -10 dB (*2)
REC: -10 dB (*2)
HEADPHONES: φ3.5 mm mini jack (3P:monaural) |
| EQUALIZER INPUT/OUTPUT |
Input: -20 dB (*2)
Output: -20 dB (*2) |
| NUMBER OF CONNECTABLECHAIRMAN/DELEGATE UNITS |
192 units |
| NUMBER OF CONNECTABLE INFRARED TRANSMITTER/ RECEIVER UNITS |
Up to 4 units (with the use of distributor
when they are all TS-905 |
| INFRARED TRANSMITTER/ RECEIVER I/O TERMINAL |
BNC jacks |
| EXTERNAL CONTROL CONNECTION TERMINAL |
D-sub connector (9P |
| LED INDICATOR |
Voting result indicators 1 – 3 (7-segment LED |
| RECORD SWITCH |
Recording start button |
| RECORDING PORTS |
USB-A (for USB memory devices) and USB Mini-B (for PCs) |
| RECORDING FUNCTION |
Recordings can be made to a USB memory device (*3) or the internal memory.
Recording format: MP3 (MPEG-1 Audio Layer-3)
Sampling frequency: 32 kHz |
| FUNCTION SWITCH |
Number of open microphones setting switch: 1/2/3/4
Mic-off setting switch: TIME OUT ON/OFF
Speech priority selector switch: FIRST (First-in-first-out priority)
LATEST (Last-in-first-out priority)
FIRST:FIXED NEXT:LATEST (Priority fixed for the first unit
out priority for all other subsequent units.)”
FBS switch: AUTO/OFF/EXT |
| OPERATING TEMPERATURE |
0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| OPERATING HUMIDITY |
90 %RH or less (no condensation) |
| FINISH |
Panel: Surface-treated steel plate |
| WEIGHT |
2.8 kg (6.17 lb) |
| ACCESSORY |
AC adapter (Cord length: 1.8 m (5.91 ft) DC cord |
| OPTION |
Rack mounting bracket: MB-TS920 |
| (*3) A USB 2.0-COMPATIBLE FAT32-FORMATTED FLASH MEMORY DEVICE OF UP TO 32 GB IN CAPACITY CAN BE USED. THERE MAY BE CASES IN WHICH A USB FLASH DRIVE CANNOT BE USED WITH THE TS-920RC |
depending on the drive’s attributes or recording conditions. |
| (*4) NOT SUPPLIED WITH THE TS-920RC(-CN). FOR THE USABLE POWER SUPPLY CORD AND AC ADAPTER |
contact your nearest TOA dealer. |
|
