Features
- Built-in weekly timer, monitor, 10 zone speaker selector, 6 channel power sequencer and Mp3 player.
- Expandable from 10 zones to 160 zones.
- Single Scheduled background music + 160 zone paging + multi voice alarm system.
- Single scheduled background music from T-6232 weekly timer's built-in MP3 player.
- 3 modes of voice alarm: all zones, separate zone and neighboring zones voice alarm.
- Remote paging console up to 16 units.
- 5 amp inputs divided into 10 zones speaker output.
- Timely broadcast up to 99 program sources.
- Broadcast modes: random, repeat and circle.
- 8 regular programs and 1 spare program for emergency/particular circumstance.
- Functional swift key for internal MP3 player priority manual broadcast.
- Zone1-10 selector, all zone selector , music/paging swtich , MP3 swift button, swift program button , power control channel 1-4 buttons, up/down/left/right/ok buttons.
- External power control, external monitor, speaker fault detection and amplifier fault changeover all are optional could be added.
- Power handling 5000W over each 10 zones.
- System communication is through CAT 5 cable.
- The system communication distance up to 1kms.
- Memory function even in case of power off.Optional
- Panel with/without handhold.
Specification
Product Model | T-6232 |
MP3 Frequency Response | 20Hz~20KHz/ ˇ1dB |
Program Steps | Total 512 Steps, 1 day 200 Steps |
Communication Protocols | RS422 |
Weight | 6.06Kg |
Zone Control | 160 zone(16pcs T-6212(A) 10 zone speaker seletor ) |
Mp3 Store Format | Compatible FAT16, FAT32 |
Power Supply | ~110V-230V 50/60Hz |
Communication Speed | 4800bps |
Dimensions | 484 x 350 x 88mm |
Communication Port | RJ45 |
Monitor Power of Speaker | 0.5W |
Total Power 5KW | |
Monitor Volume Attenuator | ~0dB |
Program Quantity | Total 9pcs(8 normal programs, 1EMC) |
Time Mode | 24 hours(hour-minutes-seconds) weekly |
Amplifier Input and Output | Integrated Terminal Block |
Voltage Output for Power Control | Integrated Terminal Block |
Audio Output | 1K¦0.775V Unbalance (6.35 RC) |
Voltage Input and Output of Alarm | 0V(Short Circuit) Industrial Standard |
Indication Method | 192x64 LCD display, English |
Function Button | Light touch press buttons include |
Power Output | ~110V-230V 50/60Hz |
