DAHUA VTO1220A Apartment Outdoor Station
VTO1220A
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Technical Specification |
|
|
Model |
VTO1220A |
|
System |
|
|
Main Processor |
Embedded Micro Processor |
|
Operation System |
Embedded LINUX OS |
|
Video |
|
|
Video Compression |
H.264 |
|
Image Sensor |
1/2.7” 1.3MP CMOS |
|
Lens |
4mm |
|
Angle of View |
D:95° H:75° |
|
Day/Night |
Color Image |
|
Audio |
|
|
Audio Compression |
G.711 |
|
Audio Input |
Omnidirectional Mic |
|
Audio Output |
Built-in Speaker |
|
Bidirectional Talk |
Support Dual-way Bidirectional talk |
|
Display |
|
|
LCD Screen |
3.5" TFT 320x240 |
|
Operation Mode |
|
|
Keypad |
Mechanical Button |
|
Reader |
Mifare Card |
|
Approaching Induction |
|
|
Body approaching |
- |
|
Interface |
|
|
Door Control |
1 |
|
Alarm In |
2(1ch unlock button, 1ch feedback) |
|
RS485 |
1 |
|
Network |
|
|
Ethernet |
10M/100Mbps |
|
Network Protocol |
TCP/IP |
|
General |
|
|
Ingress Protection |
IP54 |
|
Tamper Switch |
1 |
|
Installation |
Flush |
|
Material |
Aluminum |
|
Power |
DC 12V |
|
Power Consumption |
Standby ≤1W, Work ≤10W |
|
Working Temperature |
﹣40°C~+60°C |
|
Relative Humidity |
10%~90%RH |
|
Dimensions |
151.0mm×376.0mm×59.1mm |
|
Weight |
1.6Kg |
