HiLook DVR-216G-K1(S)

หมวดหมู่สินค้า: HILOOK

รหัส : PS09HL0504

สินค้ารับประกันคุณภาพ 2 ปี ราคายังไม่รวมค่าแรงติดตั้ง และค่าจัดส่ง ราคาสินค้ายังไม่รวมภาษีมูลค่าเพิ่ม 7%

ราคา 1,900.00 บาท

จำนวน

- +

25 ตุลาคม 2566

ผู้ชม 496 ผู้ชม

HiLook DVR-216G-K1(S)

Connectable to Turbo HD/HDCVI/AHD/CVBS signal input
Up to 2-ch 960p IP cameras input
Long distance transmission over UTP and coaxial cable
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports real-time 1080p lite and when enabled, the image effect is similar with 1080p
HDMI/VGA output at up to 1920 × 1080 resolution
One SATA interface (up to 6 TB capacity per HDD)
4/8/16-ch synchronous playback
Smart search for efficient playback
Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
VQD (Video Quality Diagnostics)
Unlock pattern for device login for the admin and clear-text password available
GUID file can be exported for password resetting and imported for finding the forgotten password
Supports PTZ control via Omnicast VMS of Genetec protocol
Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
One self-adaptive 10/100Mbps network interface
Output bandwidth limit configurable

Brand	HILOOK
Model	216G-K1S
Network	1, RJ45 10M/100M self-adaptive Ethernet interface
Interface	- 16 Video and Audio in - LAN Network Interface - HDMI Interface - USB Interface - VGA Interface - AUDIO IN - AUDIO OUT - 12 VDC Power Input - GND
Power Supply	12 VDC, 1.6 A
Power Consumption	≤ 10 W
Working Environment	Working temperature : -10 °C to 55 °C (14 °F to 131 °F) Working humidity : 10% to 90%
PoE	Yes
Video Input	IP video input - 2-ch (up to 18-ch) - Up to 5 MP resolution - Support H.265+/H.265/H.264+/H.264 IP cameras Analog video input - 16-ch - BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Video Compression	H.265 Pro+/H.265 Pro/H.265
Audio Input	1-ch, RCA (2.0 Vp-p, 1 KΩ), and 16-ch via coaxial cable
Audio Compression	G.711u
Video Frame Rate	Main stream: - For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA@15fps; CIF@25fps (P)/30fps (N) - For 720p stream access: 720p/WD1/4CIF/VGA@15fps; CIF@25fps (P)/30fps (N) - For standard definition stream access: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: - For 1080p and 720p stream access: CIF/QVGA@15fps - For standard definition stream access: CIF/QVGA@25fps (P)/30fps (N)
Video Bit Rate	64 Kbps
Audio Output	1-ch, RCA (Linear, 1 KΩ)
Audio Bit Rate	64 Kbps
Synchronous Playback	16-ch
USB Interface	2 × USB 2.0
Image Resolution	HDTVI : input 1080p25, 1080p30, 720p25, 720p30 AHD : input 1080p25, 1080p30, 720p25, 720p30 HDCVI : input 1080p25, 1080p30, 720p25, 720p30
Dimension	(W x D x H) : 26.00 x 22.20 x 4.50 cm
Net Weight	1.10 KG
