T-7704 4 CH. IP Network Adaptor
หมวดหมู่สินค้า: ITC
รหัส : PS15ITC1236
สินค้ารับประกันคุณภาพ 1 ปี ราคายังไม่รวมค่าแรงติดตั้ง และค่าจัดส่งสินค้า ราคาสินค้ายังไม่รวมภาษีมูลค่าเพิ่ม 7%
จาก 72,000.00 บาท ลดทันที 10%
ราคา 64,800.00 บาท

29 สิงหาคม 2567

ผู้ชม 278 ผู้ชม

Features

* It is a 19 rack mount IP/TCP network audio adapter, with black alumina panel, strong handle, professional mechanical assembly process, high-end appearance.

*  With embedded computer technology and DSP audio processing technology.

* Build-in 4-channel network hardware audio decoding modules, it Support TCP/IP, UDP, IGMP (multicast protocol), to realize the network transfer audio signal .

* 4-channel audio outputs to connect four power amplifiers. It adopts industrial connectors and fixing screw , with higher connection reliability than conventional connectors.

* Four independent line (AUX1/AUX2/AUX3/AUX4) audio input interfaces and network background signal mixing, with independent volume adjustment.

* With 1 AUX and Mic mix inputs, independent volume adjustment, one key to open priority, prior to network audio signal. Support zone paging (max 4 zone) function under network disconnected condition,

* With 4 independent power outputs and 2 public power outputs, it is easy to cascade with other devices. It is with intelligent power management, can automatically cut off the main power output in case of no music or paging, and make the cascaded devices enter into standby status. Meanwhile, the power output can be preset to open automatically.

* With 4-channel independent three-wire alarm relay interface, to ensure alarm can be controlled by control center, no need additional 24V DC power supply. Volume control is 3-wires connected and with no limit of quantity.

* The rear panel has 4-channel independent two-color LED indicators to display the network connection status; the front panel has 4-channel independent two-color LED indicators to display priority level, network alarm status; one power indicator to display the power status.

* Built-in dual network interface, can easily realize network port backup and cascade with other equipment, etc.

* Support 100 self-defined audio priority silence control (support multi-channel signal amplification, mixing, three-level priority control).

* Authorization operation management function, support server unified configuring and managing the user password.

* The 4-channel network hardware audio decoding modules are with independent power switch management, to easily modify the network IP decoder address.

* It Support remote hardware upgrade of the terminal, no need to upgrade at the local site, to reduce maintenance work.





Specifications





Model

T-7704

Network Interface

Stand RJ45 input (2 Group RJ45)

Transmission Rate

100Mbps

Protocol

TCP/IP,UDP,IGMP(Multicast)

Audio Formats

MP3

Audio Mode

16 Stereo CD Tone

Sampling Rate

8K~ 48KHz

Aux Input Level

Four-channels single 350mV industry standard

Audio Output Level

Four-channels 1000mV industry standard terminals

MIC Input Sensitivity

5mV

Total AUX Input Level

350mV industry standard

Harmonic Distortion

≤0.3%

Signal To Noise Ratio

>65dB

Frequency response

80Hz~16KHz

Power Supply

220VV 50Hz

Power Consumption

≤2000W

Standby Power Consumption

<10W

Working Temperature

5℃~ 40℃

Operating Humidity

20% ~ 80% relative humidity, no condensation

Size

484×303×88mm

Weight

6Kg
